| Model Number : | GD8010 |
| Image Sensor : | 1/2.7 |
| Effective Pixels: | 1.3 MP |
| Resolution: | 1920x720 at 25fps , HD 720p |
| Brand: | Fultape |
Description:
High performance 1/2.7" SONY 1.3 Mega-pixel image sensor HD/full HD Backup Camera For truck Backup Camera kit, GD8010 Side view Truck camera, perfect for truck Rear View Back up Camera Systems
Key Features:
○ High performance 1/2.7" SONY 1.3 Mega-pixel image sensor
○ Day night vision, LED white light is on for better compensation when ambient lighting
condition is not good, and IR is on at night,
○ Full color back/white modes automatic switching, Able to output extremely clear full color HD video at night , showing details on the ground to avoid accident and collision
○ IP68 Rating Waterproof
○ High elusive, better integration/combination with car/truck
○ Waterproof, anti-moisture, anti-fog lens. Vibration resistance, high temperature resistant, high humidity resistant,
○Designed for integration with Car DVD, car/truck/bus rear view LCD monitors and in dash GPS and rear view
Specifications:
| Model | GD8010 |
| Product Name | Side View Night Vision Full Color Truck Backup /reversing Camera |
| Image Sensor | 1/2.7" GC2033 |
| TV System | NTSC/PAL |
| Effective Pixels | 1.3 MP |
| Sensing Area | 2.7μm（H）ⅹ 2.7μm（V） |
| Sync. System | Internal |
| Resolution | 1920x720 at 25fps , HD 720p |
| Minimum Illumination | 0.1 Lux (day), 0 Lux (with IR) |
| Video Output | 1.0 Vp-p/75 Ohm |
| Scanning System | interlace |
| AGC | Automatic |
| Signal to noise ratio | Better than 48dB |
| White Balance | Automatic |
| Gamma Consumption | 0.45 |
| Electronic Shutter | Automatic |
| Backlight Compensation | Automatic |
| IP Rating | IP68 rated waterproof |
| Power Supply | DC 12V~24V |
| Lens | 2.7mm |
| Lens Angle | 122° |
| Current | 70±5mA |
| Operating Temperature | -20℃-70℃,RH 95% MAX |
| Storage Temperature | -30℃-80℃,RH 95% MAX |
| Product size | 45*52*40mm |
