Buy FULTAPE P0.9375 Small Pixel Pitch LED Display, ultra-thin ultra-light

Item ID:
F-I-P0.9375U
Stock:
10000
Price:
$13,388.99
Quantity:
Sold Out
DescriptionSpecificationsShippingWholesale Inquiry
Item Number :F-I-P0.9375U
Pixel Pitch:0.9375mm
Thickness of cabinet48mm
Net weight : 7.0KG
Resolution:HD
Brand:FULTAPE


Fine pixel pitch  LED Display screen features


● Amazing Ultra HD resolution,

● Highly advanced technology of low brightness high grey level, 8000:1 high contrast ratio,

3840 Hz high refresh rate

● Wide color gamut, best color uniformity (consistency) and saturation, no tailing , no overlap

● 99.8% High color and brightness uniformity

● Finest natural vivid picture, but eye-care when watching a long time

● 170(H)/170(V) degrees super wide view angle,

● 3840Hz ultra high refresh rate to eliminate trailing

● Front accessible cabinet, able to install from front and rear, easy maintenance

● CNC precision manufactured die-casting aluminum cabinet with excellent flatness

● True zero gap Seamless led video wall, tolerance gap between cabinets is less than 0.1mm

● Excellent ventilation with fan-less ultra quiet design

● Ultra-thin cabinet, only 48mm thickness

● Extremely light weight cabinet, only 7.0KG

● CE,FCC and Rosh certified, 10,000 hours lifetime



Specifications

Model F-I-P0.9375U F-I-P1.25U F-I-P1.56U F-I-P1.87U
Product name Ultra-thin extremely light weight fine pixel pitch Indoor  full color HD LED display
LED wave length R: 619-624nm, G: 522-526nm, B: 469-474nm
Pixel
Pixel pitch                                0.9375mm 1.25mm 1.56mm 1.875mm
Pixel configuration 1R1G1B 1R1G1B 1R1G1B 1R1G1B
LED Encapsulation                                     Mini 4-In-1 Mini 4-In-1/SMD1010(bk) Mini 4-In-1/SMD1010(bk) Mini 4-In-1/SMD1515(bk)
Brand of LED NationalStar
Module
Resolution of module 160*180 120*270 96*108 80*180
Size of module                          150*168.75 150*337.5 150*168.75 150*337.5
Modules/cabinet(L*H) 4x2 4x1 4x2 4x1
Cabinet
Resolution of  cabinet  640*360 480*270 384*216 320*180
Size of standard cabinet                  600(L) x 337.5(H)x48 (D)  600(L) x 337.5(H)x48 (D)  600(L) x 337.5(H)x48 (D)  600(L) x 337.5(H)x48 (D)
Cabinet material Die casting aluminum alloy
Maintenance  Front accessible
Thickness of  cabinet  48mm
Weight of cabinet
7.0 kg

7.0 kg

7.0 kg

7.0 kg
Panel
Pixel density                                   1,137,778dots/m² 640,000dots/m² 409,600dots/m² 284,444dots/m²
Resolution of LED wall Ultra-FHD 4K,3840X2160 Ultra-FHD 4K,3840X2160 Ultra-FHD 4K,3840X2160 Ultra-FHD 4K,3840X2160
Brightness
(white balance)
 600CD / m²
adjustable
 600CD / m²
adjustable
 600CD / m²
adjustable
 600CD / m²
adjustable
Color Temperature 1000K~18500K adjustable 1000K~18500K adjustable 1000K~18500K adjustable 1000K~18500K adjustable
Contrast ratio 8000:1 8000:1 8000:1 8000:1
Grey scale  16 bits/65,536 levels 16 bits/65,536 levels 16 bits/65,536 levels 16 bits/65,536 levels
Color Uniformity 99.8% 99.8% 99.8% 99.8%
View angle                    H:170°; V:170°  H:170°; V:170°  H:170°; V:170°  H:170°; V:170°
Optimal view distance 2-20M 2-20M 2-20M 2-20M
Average power consumption/sqm 100Watts 100Watts 100Watts 100Watts
Max. power consumption
420Watts /m2

420Watts /m2

420Watts /m2

420Watts /m2
Refresh rate                                       3840HZ 3840HZ 3840HZ 3840HZ
IP rating
IP34 Waterproof & dustproof ( front and back )
Control

Driving mode
Constant current driving Constant current driving Constant current driving Constant current driving
1/30scan   1/27 scan ; 1/30 scan  ;1/45 scan 1/27 scan ; 1/28 scan   1/30 scan
Signal Interface  Ethernet (network) interface
Support input  source                                RF,RGB,RGBHV, HDTV, SDI, HD-SDI, S-video, composite,DVI,etc
Control mode Synchronous display with control PC by DVI
Control distance Cat5 Ethernet cable 120m ; Optical fiber : 10000m
Operation
Power supply  90~264 V AC , 47~63 Hz
MTBF 5,000 hours  5,000 hours  5,000 hours  5,000 hours
Lifespan                                                   75,000 ~100,000 hours  75,000 ~100,000 hours  75,000 ~100,000 hours  75,000 ~100,000 hours
Out of control rate                                     <0.0001   <0.0001   <0.0001   <0.0001
Operation temperature Minus 20~60 Minus 20~60 Minus 20~60 Minus 20~60
Operation  humidity 10%~95%RH 10%~95%RH 10%~95%RH 10%~95%RH
Storage & Application
Storage temperature Minus 40~85 Minus 40~85 Minus 40~85 Minus 40~85
Storage humidity 30%~60%RH 30%~60%RH 30%~60%RH 30%~60%RH
