How to install Indoor P5 Fixed LED Displays Screens | fultape.cc

Item ID:
F-I-P5
Stock:
10000
Price:
$599.99
Quantity:
Sold Out
DescriptionSpecificationsShippingWholesale Inquiry
Item Number :F-I-P5
Pixel Pitch:5mm
Thickness of cabinet60-130mm
Net weight : 8.0KG
Brand:FULTAPE


Fixed Indoor P2.5 ,P3, P4, P5,P6  LED screens / LED displays





FULTAPE electronics has been committed to developing and manufacturing a full range of high quality fixed indoor outdoor LED screens, LED displays, LED video wall, pixel pitch ranges from 2.5mm to 10mm with different sizes to fit different kinds of applications.



The cabinets of the P2.5 , P3, P4, P5,P6 fixed indoor outdoor LED screens, LED displays and LED video walls are manufactured by sophisticated precision CNC machines and feature special structure designs of precision alignment and quick assembly to allow users finish installation easily. What’s more, they enjoy the following advantages.





● SMD 3-IN-1 full color indoor fixed LED display screens



● High brightness, high contrast ratio,



● High refresh rate, high grey scale,



● High color and brightness uniformity



● Fine, Clear and vivid image and video



● Slim and Super light weight, easy to carry and install



● 160(H)/160(V) degrees wide view angle,



● Metallic or die-casting aluminum cabinets



Technical specifications
Model F-I-P5 F-I-P6
Product name Indoor  full color LED display
LED wave length R: 620-625nm, G: 520-525nm, B: 465-470nm
Pixel
Pixel pitch                                5mm  6mm
Pixel configuration 1R1G1B 1R1G1B
LED Encapsulation                                     SMD3528 SMD3528
Module
Resolution of module 64*32 32*32
Size of module                          320*160 192*192
Weight of module  225.7+10g 143.5+10g
Modules/cabinet(L*H) 2x4 3x3
Cabinet
Resolution of  cabinet  128*128 96*96
Size of  cabinet                  640(L) x 640(H) mm   576(L) x 576(H) mm
Cabinet material Aluminum alloy &steel (plate metal)optional
Thickness of  cabinet  Aluminum alloy:6-16cm,steel :8-16cm
Weight of cabinet  Aluminum alloy:11kg,
steel :18kg
Aluminum alloy:11kg,
steel :20kg
Panel
Pixel density                                     40,000 dots/m² 27,777 dots/m²
Brightness                                          1800CD / m²  1800CD / m²
Grey scale  12 bits/4096 levels 12 bits/4096 levels
Colors 68.7 Billion 68.7 Billion
View angle                    H:150°; V:120°  H:150°; V:120°
Optimal view distance 4-38M 4-38M
Power consumption 250 Watts/sqm(Average) 250 Watts/sqm(Average)
750 Watts /m2(Max.) 700 Watts /m2(Max.)
Refresh rate                                       1200HZ 1200HZ
Control
Driving mode                                      1/16 scan & constant current driving
Signal Interface  Ethernet (network) interface
Support input  source                                RF,RGB,RGBHV, HDTV, SDI, HD-SDI, S-video, composite,DVI,etc
Control mode Synchronous display with control PC by DVI
Control distance Cat5 Ethernet cable 120m ; Optical fiber : 10000m
Operation
Power supply  110V/220 V AC , 50HZ/60 Hz
MTBF 5,000 hours  5,000 hours
Lifespan                                                  75,000 ~100,000 hours 75,000 ~100,000 hours
Out of control rate                                     <0.0001   <0.0001
Operation temperature Minus 20~60 Minus 20~60
Operation  humidity 10%~95%RH 10%~95%RH
Storage & Application
Storage temperature Minus 40~85 Minus 40~85
Storage humidity 30%~60%RH 30%~60%RH
Application For indoor use , for rental
